Cycloidal pin gear reducer is a novel transmission machine with less tooth difference planetary transmission principle and cycloidal pin tooth meshing according to JB/T2982, which is widely used in textile printing and printing, light industry food, me tallurgical miners, petrochemical, lifting and transportation and construction machinery and other fields of drive and deceleration devices.
▍Product Features
A cycloidal pin gear reducer is an advanced transmission device based on the planetary transmission principle and cycloidal pin tooth meshing technology according to JB/T2982 standards. With high efficiency, compact structure and reliable performance, this cycloidal speed reducer is widely used in textile machinery, printing equipment, food processing, metallurgy, mining, petrochemical, lifting and construction machinery.
As a high-performance cycloidal gearbox, it provides stable speed reduction and high torque transmission for various industrial applications.
▍Key Advantages of Cycloidal Pin Gear Reducer
1. High Reduction Ratio and High Efficiency
The cycloidal speed reducer achieves a high single-stage reduction ratio of up to 1:87 with transmission efficiency exceeding 90%. Multi-stage combinations can provide higher reduction ratios for applications requiring lower output speed and higher torque.
2. Compact Structure and Small Size
Based on the planetary transmission principle, the input shaft and output shaft are arranged on the same axis, allowing the cycloidal gearbox to achieve a compact design, small footprint and high torque density.
3. Easy Installation and Maintenance
The optimized structural design of the cycloidal pin wheel reducer allows convenient installation, disassembly and maintenance, reducing equipment downtime and improving operational efficiency.
4. Smooth Operation and Low Noise
The cycloidal pin gear reducer features multiple tooth engagement with a high overlap coefficient, ensuring stable transmission, reduced vibration and low operating noise compared with traditional gear reducers.
5. Long Service Life and High Reliability
The main transmission components are manufactured from high-quality bearing steel with excellent mechanical properties. The rolling friction structure reduces wear and improves the durability and service life of the industrial cycloidal gearbox.
6. Strong Overload Capacity and Impact Resistance
The cycloidal speed reducer offers excellent overload capability, strong impact resistance and a low moment of inertia, making it suitable for frequent starting, stopping and forward/reverse rotation applications.
▍Parameter
| Product Name | BLEY/XLEY series Cycloid Pin Weel speed reducer |
| Power | 0.18KW~15KW |
| Torque | 120Nm~30000Nm |
| Running direction | Forward and reverse |
| Gear material | Cast iron |
| Noise test | Below 65dB |
| Brand of bearings | C&U bearing, ZWZ, LYC, HRB, NSK , etc |
| Brand of oil seal | NAK or other brand |
| Temp. rise (MAX) | 40ºC |
| Temp. rise (Oil)(MAX | 50ºC |
| Vibration | ≤20µm |
| Housing hardness | HBS190-240 |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Heat treatment | Carburizing, Quenching etc |
| Efficiency | 90% (depends on the transmission stage) |
| Installation type | Foot plate horizontal installation, flange type vertical installation; |
| Input method | Flange input(AM), shaft input(AD), inline AC motor input, or AQA servo motor |
▍FAQ About BWY-XWY Cycloidal Gearbox
What is a horizontal cycloidal gearbox?
A horizontal cycloidal gearbox is a cycloidal transmission device designed with a horizontal installation structure to provide high torque and stable speed reduction for industrial machinery.
What are the advantages of a cycloidal pin gear speed reducer?
A cycloidal pin gear speed reducer provides high torque capacity, excellent overload resistance, smooth operation and long service life.
What industries use cycloidal pin wheel reducers?
A cycloidal pin wheel reducer is commonly used in conveyors, mixers, packaging machines, chemical equipment and heavy industrial machinery.
Is BWY-XWY series cycloidal gearbox suitable for heavy-duty applications?
Yes. The BWY-XWY horizontal cycloidal speed reducer is designed for industrial applications requiring high torque output and reliable continuous operation.
