BWY/XWY Series Foot Mounting Cycloidal Gearbox with Motor adopts a high-strength cycloidal pinwheel transmission structure combined with a foot mounting design and motor direct connection, providing a complete drive unit with high torque capacity, stable operation, easy installation and excellent overload resistance. The foot mounting structure offers flexible installation solutions and is suitable for industrial applications requiring strong load capacity, reliable low-speed transmission and continuous heavy-duty operation. With a typical output torque range of 100–60,000 N·m and motor power range of 0.12–75 kW, it is widely used in conveyors, mixers, crushers, production lines, mining equipment and heavy industrial machinery.
| Item | Specification |
| Product Series | BWY/XWY Series |
| Gear Type | Cycloidal Pinwheel Gear |
| Transmission Structure | Cycloidal Disc Transmission |
| Mounting Type | Foot Mounted |
| Input Type | Motor Direct Input |
| Output Shaft Type | Solid Shaft / Hollow Shaft Optional |
| Housing Material | Cast Iron |
| Cycloidal Disc Material | Alloy Steel |
| Pin Gear Material | Hardened Steel |
| Lubrication | Grease or Oil Lubrication |
| Protection Grade | IP54 / IP55 Optional |
| Efficiency | Up to 94% |
| Ratio Range | 11–7569 |
| Motor Power Range | 0.12–75 kW |
| Output Torque | 100–60,000 N·m |
| Installation Direction | Horizontal Installation |
| Model | Frame Size | Ratio Range | Motor Power (kW) | Output Torque (N·m) |
| BWY/XWY1 | 1 | 11–87 | 0.12–1.5 | 100 |
| BWY/XWY2 | 2 | 11–121 | 0.25–3 | 300 |
| BWY/XWY3 | 3 | 17–187 | 0.55–5.5 | 800 |
| BWY/XWY4 | 4 | 17–289 | 1.5–11 | 2,000 |
| BWY/XWY5 | 5 | 23–473 | 3–22 | 5,000 |
| BWY/XWY6 | 6 | 29–7569 | 5.5–45 | 15,000 |
| BWY/XWY7 | 7 | 35–7569 | 11–75 | 30,000 |
| BWY/XWY8 | 8 | 35–7569 | 22–75 | 60,000 |
Note: Customized mounting dimensions, motor specifications, output shaft configurations, reduction ratios and special heavy-duty transmission solutions are available upon request.
